Sonance IS6T Invisible Speaker
$0.00
Invisible Speakers are the pinnacle of the Sonance “Designed to Disappear” strategy. High frequencies are achieved with Sonance’s “Motion Flex Technology”, which consists of a “Wave Flex Drive Unit” with a bending wave diaphragm, utilizing a 1.75” (44mm) voice coil, while the low frequencies are generated by an “Air Flex” Woofer with an air pulse diaphragm driven by an 6.5” (165mm) carbon fiber woofer.
Specifications
- Wave Flex Drive Unit: 20in^2(127cm^2) bending wave diaphragm. 1.75in (44mm) voice coil
- Air Flex Woofer: 98in^2 (633cm^2) air pulse diaphragm, 6.5in (165mm) carbon fiber woofer
- Frequency Response (+/- 3db): 50Hz - 30kHz
- Power Handling (RMS): 100 watts RMS
- Sensitivity: 84dB (2.83V/1m)
- Nominal Impedance (Ohms): 4 ohms
- Dispersion: 170 degree hemispherical up to 10kHz
- Transformer Taps: 70 V / 100 V: 30W, 15W and 7.5W
- 70 V: 3.8W: Dimensions (WxHxD)
- 16.1" x 16.1" x 3.15" (408.94mm x 408.94mm x 80.01mm): Mounting Depth
- 3.39" (86.11mm): Architectural Specifications
- The loudspeaker shall be of the two-way type comprising a single cabinet that is designed to inst...: Dimensional Drawings
