Sonance PS-P85T Commercial Speaker
$0.00
The PS-P85T is a high-output pendant loudspeaker for professional commercial installations. Sharing the same 8" aluminum cone driver and neodymium compression driver platform as the PS-C85RT, it delivers 88dB sensitivity and selectable 120°/80° dispersion with full 70V/100V transformer compatibility. Explore the full high-output family here.
Specifications
- HF Driver: 1.4" (36mm) aluminum dome compression driver, 36mm Voice Coil Size, 1" (25mm) Exit Size, Neodymiu...
- LF Driver: 8" (203mm) aluminum cone, Santoprene surround, 60.55mm Voice Coil Size, Ferrite Magnet
- Frequency Response (+/- 10db): 36.6Hz - 25kHz
- Frequency Response (+/- 3db): 41.4Hz - 20kHz
- Power Handling (RMS): 150 watts (600 watts peak), 100 hours
- Sensitivity: 88dB (2.83V/1m)
- Enclosure: Polypropylene plastic (UL94V-0)
- Rated Maximum SPL: 109dB @ 1 meter (3.3 feet), 115dB peak
- Nominal Impedance (Ohms): 8 ohms
- Transformer Taps: 70 V / 100 V: 120W, 60W and 30W
- 70 V: 15W: Coverage Pattern 1kHz to 10kHz
- 120 or 80 Degree Axis Symmetric: Dimensions (Diameter x D)
- 11.17" x 24.69" (283.72mm x 627.13mm): Weight
- 23.55 lbs. (10.68kg): Grille
- Steel: Input Connector
- Four pin, Euroblock with loop output connections: Certifications
- UL 1480A, CSA-C22.2 No.205, NFPA70, NFPA 90A: Suspension Points
- Back: Maximum SPL (Peak)
- 115dB peak: Architectural Specifications
