Sonance PS-C43RT Commercial Speaker
$0.00
The Sonance PS-C43RT in-ceiling speaker features a bezel-less magnetic grille, optional square adapter, high-excursion woofer, and pivoting tweeter for precise sound coverage. Its sealed metal enclosure includes cable clamping, a removable Euroblock connector, and seismic attachment. UL 1480 and UL 2043 certifications ensure safety and reliability in installations.
Specifications
- HF Driver: 1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled
- LF Driver: 4" (100mm) Polypropylene Cone, Butyl Rubber Surround
- Frequency Response (+/- 10db): 57Hz - 25kHz
- Frequency Response (+/- 3db): 75Hz - 20kHz
- Power Handling (RMS): 60 watts program, 30 watts pink noise
- Sensitivity: 87dB (2.83V/1m)
- Rated Maximum SPL: 105dB @ 1 meter (3.3 feet), 110dB peak
- Nominal Impedance (Ohms): 8 ohms
- Transformer Taps: 70 V / 100 V: 30W, 15W and 7.5W
- 70 V: 3.8W: Dimensions (Diameter x D)
- 6.3" x 7.01" (160.02mm x 178.05mm): Cut-Out Dimensions (Diameter)
- 5.875" (149.23mm): Knockout
- One, Side mounted 0.75" (19mm): Weight
- 5.63 lbs. (2.55kg): Grille
- One Piece Paintable Grille with Magnetic Retention: Input Connector
- Four pin, Euroblock with loop output connections: Certifications
- UL 1480, UL 2043, NFPA 90A, NFPA 70: Suspension Points
- One, on top surface: Maximum SPL (Peak)
- 110dB peak: Architectural Specifications
