Sonance CCA10i-BA-W Commercial Speaker
$0.00
Constant Curvature Array coherent point source speaker with Blaze 160° symmetrical horizontal pattern control, passive, bi-amped, white
Specifications
- Speaker Tweeter: Coaxial: 4" Voice Coil mid driver; 2.55" Voice Coil HF tweeter
- Speaker Woofer: Dual 10" with 2.5" Voice Coils
- Frequency Response (+/- 10db): 45Hz - 18kHz
- Frequency Response (+/- 3db): 52Hz - 18kHz
- Power Handling (RMS): LF: 500W AES (2000W peak) @4Ω
- HF: 110W AES (440W peak) @8Ω: Enclosure
- Baltic birch plywood, engineered plastics, and aluminum frame: Dimensions (WxHxD)
- 32.3" x 13.23" x 18.25" (820.42mm x 336.04mm x 463.55mm): Weight
- 83 lbs. (37.65kg): Grille
- 14-gauge (2mm) perforated steel, powder-coated finish, white: Suspension Points
- Install side rigging, optional array frame accessories.: Coverage (-6dB)
- Horizontal: 160°: Vertical: 20°
- Pressure Sensitivity @ 1W/1m: LF: 101dB HF: 111.4 dB
